Zeroplus LAP-C (162000)
Logic & Protocol Analyzer, 16 ch@2MBit, 100Hz-200MHz, USB Power
202 The Zeroplus Logic Analyzer User’s. As with proper installation of many USB devices, the Logic Analyzer application and driver software must be.
The Zeroplus LAP-C (162000) is a 16-Channel, PC-based Logic Analyzer that features powerful protocol analyzer capabilities. The standard package includes the UART, IIC, SPI, 7-Seg, 1-Wire, CAN2.0B, Microwire, SSI, Manchester, Miller, LCD1602, IRDA, DigitalLogic, 3-Wire, ArithmeticalLogic, UpDownCounter, USB1.1, JTAG2.0 & PS/2 Protocol Analyzer plug-ins. You will also receive printed instructions on how to activate the remaining protocol decoder plugins of your choice for free. This is the List of all available protocol decoder plugins.
If you have installed ZeroPlus Driver before, remove it and retry; Disable antivirus and retry; Run the program as administrator If you have tried all the methods above and your problem still exists, log on to Brook’s official website, go to “Contact us” for assistance. Q: Do I need to do firmware update if there's new release? LAP-F14064M logical analyzer is multi-purpose and PC-based logic analyzer, with 40 channels and 64Mb memory depth. Significantly he has demonstrated the power of team creativity—effective teamwork is a key driver in creative outcomes. Donald has experience as a designer in both the UK and Australia. For many years he was consultant to Minale Tattersfield Bryce Design Strategy also teaching for over twenty years at Griffith University. Computer Device Drivers - Update your computer's drivers using DriverMax, the free driver update tool.
The Zeroplus patented waveform compression technology increases the effective sample memory capacity far beyond the physical 32MBit. All 16 channels of the LAP-C (162000) can achieve a compression rate up to 255× depending on the data content, allowing you to obtain considerably more sampling data.
Zeroplus Lap-c Driver
The logic analyzer connects to a PC via USB. It supports the full 480Mbps USB 2.0 speed, but also can use 12Mbps USB 1.1. The analyzer is powered directly from the USB.
Features
- Model Type : PC Based Logic Analyzer
- Operating systems : Microsoft Windows (2000/XP/Vista/Vista64/Win7-32/Win7-64)
- Interface : USB2.0 (1.1)
- Power : USB
- Power Dissipation (running) : max. 2W
- Sample rate : Internal clock (Timing Mode) 100Hz - 200MHz
- Sample rate : External clock (State Mode) 100MHz
- Bandwidth : 75MHz
- Total Memory : 32MBit
- Memory depth (per channel) : 2MBit
- Memory depth with compression enabled (per Channel) : up to 512MBit (best case)
- Trigger condition : pattern / Edge
- Trigger channel : 16 channels
- Pre/Post trigger
- Threshold Voltages : Working range -6V~+6V
- Threshold Voltages : Accurate rate -/+ 0.1V
- Maximum input voltage : +/- 30V
- Impedance : 500kOhms/10pF
- Data Skew <1.5ns
- Dimensions: 130 x 100 x 30mm
- I2C, SPI, UART (RS232 & RS485), 7-Segment, 1-Wire, Manchester, Miller, Microwire, SSI & CAN 2.0b included
- All available protocol decoder plugins of your choice for free
System Requirements
- Microsoft Windows (2000/XP/Vista/Vista64/Win7-32/Win7-64)
- 300 MHz CPU or faster
- 256MB RAM or more
- 100MB available disk space
- 1 USB Port
Downloads
Zeroplus Usb Driver
Package Contents
- LAP-C (162000) logic analyzer unit
- Protocol Analyzer software plug-ins for I2C, SPI, UART, 7-Segment, 1-Wire, Manchester, Miller, Microwire, SSI & CAN 2.0B
- All available protocol decoder plugins of your choice for free
- USB cable
- Two 8-channel signal connectors
- One 2-channel signal connector
- One single-channel signal connector
- 20 test hook grips in 10 different colors
- Software CD-ROM or USB-Key
- Printed User Manual
Zeroplus Usb Driver Brook
The included signal connector cables are 25cm in length. A 40cm cable package is available separately: Contact
